Jim Black Elliptical Opening Portlight - Stainless Steel Trim - 159mm Wide
A portlight featuring a high impact U.V. resistant Saralon resin moulded frame which resists warping and is impervious to harsh chemicals. The light bronze finished 6mm tempered glass lens offers extreme strength and durability and is moulded into the frame to help protect against water intrusion and lens separation.
Each portlight is supplied with an external stainless steel trim ring and features a strong friction hinge which holds the port window open at a chosen position. Robust quick action friction locking tabs secure the lens frame against the inset seal to prevent water ingress. Supplied complete with matching trim ring flange and insect screen.
Features:
- U.V. stabilised Saralon resin moulded frames
- Chemical resistant
- Custom seal prevents water ingress
- 6mm tempered glass for strength and clarity
- Attractive stainless steel external trim ring
- CE certified
- Includes insect screen
| Part Number | Shape | Outside | Inside | Cut Out | Maximum Hull Thickness |
|---|---|---|---|---|---|
| BLA-171506 | Elliptical | 159mm x 464mm | 77mm x 381mm | 97mm x 398mm | 19mm |
